Off the floor · Studs & Stud Bolts
1-1/8"-8 UN-2A x 6" All Thread Studs with Deformed Thread
Inconel 718 (ASME SB637). Machined to the customer's drawing in our Houston shop.
Job details
PartAll Thread Studs with Deformed Thread
Thread1-1/8"-8 UN-2A
Length6"
MaterialInconel 718 (ASME SB637)
Grade pageInconel 718
Product familyStuds & Rods
Made inHouston, Texas · ISO 9001 certified
1-1/8"-8 UN-2A x 6" (+/- 0.06") all thread studs with a deformed thread, made from ASME SB637 Alloy 718.
Studs are cut from certified bar, threaded by rolling or single-point cutting to the class called out, and chamfered and marked before they leave. Double-end and tap-end patterns, special lengths and drilled or coated variants are all made to the drawing.
About the material: The premier high-strength nickel superalloy — 185 ksi tensile and 150 ksi yield from cryogenic temperatures to 1200 °F, with corrosion and sour-gas resistance to match. Read the Inconel 718 data page →
