3/8"-16 UNC-2A x 2-3/4" Socket Head Screw
17-4 PH Stainless. Machined to the customer's drawing in our Houston shop.
Job details
PartSocket Head Screw
Thread3/8"-16 UNC-2A
Length2-3/4"
Material17-4 PH Stainless
Grade page17-4 PH
Product familySocket Products
Made inHouston, Texas · ISO 9001 certified
3/8"-16 UNC-2A × 2-3/4" socket head screw to drawing in 17-4 PH stainless steel.
Special socket products are machined from bar where the specification allows, with the socket broached and the threads rolled, or cut where the specification or order allows, then heat treated and plated as the specification requires. Shoulder, low-head, flat-head and set-screw patterns follow ASME B18.3 unless the drawing says otherwise.
About the material: The high-strength stainless — up to 190 ksi in H900, or 115 to 135 ksi with real toughness in the H1150 conditions — for pump shafts, valve stems, subsea and aerospace fasteners. Read the 17-4 PH data page →
