Off the floor · Machined Components · posted 1w ago
1.621" x 4.28" Pin Guide
ASTM A108 Grade 1018, zinc plated. Machined to the customer's drawing in our Houston shop.
Job details
PartPin Guide
Length4.28"
MaterialASTM A108 Grade 1018, zinc plated
Product familyMachined Components
Made inHouston, Texas · ISO 9001 certified
1.621" x 4.28" Pin Guide manufactured from ASTM A108 Grade 1018 steel and zinc plated per ASTM B633 Type II, SC4 for added corrosion resistance and dependable performance. ASTM A108 Grade 1018 1.621" x 4.28" Zinc Plated.
Machined components are built to print from certified bar: turned, milled, drilled and tapped, then inspected against the drawing before shipment. Pins, sleeves, plugs, fittings and adapters are typical of this work.
