5/8"-11 UNC-2A x 2.25" Hex Head Cap Screw
ASTM A193 B8 Class 2 (304 stainless). Machined to the customer's drawing in our Houston shop.
Job details
PartHex Head Cap Screw
Thread5/8"-11 UNC-2A
Length2.25"
MaterialASTM A193 B8 Class 2 (304 stainless)
Grade pageA193 B8 Class 2
Product familyBolts & Screws
Made inHouston, Texas · ISO 9001 certified
5/8"-11 UNC-2A x 2.25" hex head cap screw made from ASTM A193 B8 Class 2 for a returning customer, with clear stamping.
Headed fasteners are turned or forged to the pattern on the drawing, threads rolled or cut to class, and supplied with the finish specified. Heavy hex, 12-point flange, eye and special-head styles are routine work here.
About the material: 304 stainless bolting cold worked after solution treatment — 125 ksi tensile in ¾ in. and under, with strength stepping down by diameter to 1½ in. Read the A193 B8 Class 2 data page →
